TCS BUBBLER

TCS Bubbler delivers controlled TCS vapor for epitaxy via hydrogen bubbling, with PLC control, real-time monitoring, and tool interlock safety.

Home Process Tools LIQUID TOOLS TCS BUBBLER
Background
Integrated Complex Equipment

BUBBLER(Liquid Bubbling System)

Background Equipment
TCS Bubbler delivers controlled TCS vapor for epitaxy via hydrogen bubbling, with PLC control, real-time monitoring, and tool interlock safety.

System Features

  • ◆ Precise process control: Uses hydrogen carrier gas to bubble TCS liquid at constant temperature, generating process gas with controllable flow rates.
  • ◆ PLC-based system: Controlled by Omron/Siemens PLC with a 10-inch color touchscreen HMI for intuitive operation.
  • ◆ Safety & monitoring: Supports interlock connection with production tools, real-time equipment status display, and user permission management.
  • ◆ Flexible bubbler options: Available in 4L and 14L volumes, with operating pressure up to 4 bar (design pressure 10 bar).
  • ◆ Utilities compatibility: Requires 7 barg pneumatic supply, exhaust (150 m³/hr), and UPS power (110/240VAC, 1kVA); optional cooling water support.
  • ◆ Overall Dimensions (L×W×H):550 × 600 × 2130 mm
  • ◆ Sampling port; compatible with multiple analyzers

Get started with SUNTO

Cookies settings

It can achieve continuous and uninterruptedsafe supply of electronic-grade specialtygases at high flow rates and is mainlycontrolled by PLC. The touch screen is thehuman-machine interface.
